High-density Ceiling-mounted Wireless AP

Supports AP Mode, Routing mode, Bridging Mode

Supports IPv4, DHCP, NTP protocols

Supports address acquisition methods such as static IP assignment, dynamic DHCP, and PPPoE

CAPWAP and MQTT

Supports discovery of AC through Option 43, DNS, etc.

Supports Layer 2 and Layer 3 networking of AC and AP

Supports cross-NAT networking for AC and AP

Supports user roaming based on Layer 2 and Layer 3

Supports clock synchronization, version synchronization, and configuration synchronization between AC and AP

Supports 802.11 protocol suite

Supports multi-SSID management, Chinese SSID and SSID hiding

Supports unbinding of SSID and VLAN

Supports SSID-based user limit and isolation

Allows setting individual parameter templates for each SSID

Supports country code settings

Supports local authentication and Cloud authentication

Supports multiple authentication methods such as local account, SMS, WeChat, and vouchers

Supports user whitelist and blacklist

Controls user access time and bandwidth

Supports 802.11e/WMM

Supports global traffic rate limit

Provides traffic rate limiting based on AP, VLAN, and user

Supports user load balancing based on wireless frequency bands and APs

Supports one-click automatic network optimization and custom RF parameter settings

Default 8 wireless scene templates, supports user-defined templates

Supports automatic background optimization without manual intervention

Supports 5G prior access, supports restrict access of low-rate users

Supports PSK authentication method

Supports WEP, WPA, WPA2, WPA3 wireless encryption

Supports security filtering based on IP and MAC

Protects against DDoS, De-Auth, and similar attacks

Supports Rogue AP detection

Supports traditional device management such as Telnet, SSH, Web, SNMP and Cloud

Offers diagnostic tools such as ping, tracert, and debug

Supports centralized AC management via CAPWAP and MQTT

Supports PALLAS unified cloud management

Support AP indicator light control
